NPT Round Cross
Sizes available
Our Round NPT Crosses range in size from 1/8″ to 1″. Again be careful, the size is different than the OD (outter diameter).
| DESCRIPTION | PL PART # | (A) OD | (B) OAL | (C) Thru Ø | Connection A | WEIGHT (LBS) | QUOTE |
|---|---|---|---|---|---|---|---|
| 1/8 NPT ROUND | 2NX15 | 1.500 | 0.63 | 0.339 | .23 | ||
| 1/4 NPT ROUND | 4NX15 | 1.750 | 0.75 | 0.437 | .33 | ||
| 3/8 NPT ROUND | 6NX15 | 2.00 | 0.88 | 0.578 | .46 | ||
| 1/2 NPT ROUND | 8NX15 | 2.250 | 1.13 | 0.718 | .73 | ||
| 3/4 NPT ROUND | 12NX10 | 3 | 1.38 | 0.922 | 1.65 | ||
| 1 NPT ROUND | 16NX10 | 4 | 1.75 | 1.156 | 3.94 | ||
| 1/4 BSP ROUND | 4BX30 | 1.750 | 0.75 | 0.203 | .37 |
